Sidewalk doors are most commonly found in commercial and industrial settings, such as restaurants, retail stores, and warehouses. These allow for easy movement of people and products and can be customized with different colors and finishes. Steelway’s diamond plated sidewalk doors feature a locking mechanism for additional security.
We have been serving the Continental United States and manufacturing our products in the U.S.A. since 1963! We install Steelway aluminum sidewalk doors to offer you a new entry point into your home or business.
Enhance your property with an additional entrance. Contact Steelway Cellar Doors today at +1-877-553-2610.
3/16: Diamond Plate Door Panels, 1/4” Angle Iron Frame, All Welded Seams Ground Smooth, Primer and Finish Coat of Paint, Additional Locking and Safety Options
Steelway use 1/2” x 1“ stainless steel bar stock with a stainless steel 3/8” hinge pin for rugged durability even in the most demanding commercial applications.
Our strong 3” x 3” x 1/4” angle iron frame is welded to our exact dimensions and all the seams are ground smooth for the correct fit and a professional finish that will last for decades.
All Steelway Diamond Plate Doors have a solid smooth steel handle on the right door for easy pull up and no maintenance. We use our recessed Steelway handle whenever possible.
Keeping your access secure is as easy as specifying where you want your padlock tabs. Just tell your salesperson what your locking needs are and we will solve your problem.
If this is new construction, we can weld #4 rebar studs under the frame to make the unit is permanently secure.
We understand that not all diamond plate doors have to be custom made so we have introduced a line of Standard sidewalk doors all designed to fit Standard openings or as a quick solution when you are pouring new sidewalks. All our standard doors support 300lb/s.f. live load and are in stock ready for same day shipping.
Outside Width | Outside Length | Concrete Opening Dimensions | Door Opening Dimensions |
---|---|---|---|
41 1/4″ | 41 1/4″ | 36″ W x 36″ L | 35 1/4″ W x 35 1/4″ L |
53 1/4″ | 53 1/4″ | 48″ W x 48″ L | 47 1/4″ W x 47 1/4″ L |
53 1/4″ | 65 1/4″ | 48″ W x 60″ L | 47 1/4″ W x 59 1/4″ L |
All doors are prime coated with one finish coat of black paint. The frame lays flat on all four sides and can have 4″ rebar studs welded to the frame if the door is to be poured-in-place.
SPECIFICATIONS FOR PEDESTRIAN SIDEWALK DOORS
Sidewalk doors shall be a steel door manufactured by Steelway Cellar Doors LTD, King of Prussia, PA. Door panels will be fabricated of 3/16: diamond plate steel designed and reinforced to support a 300 lb/sf live load with a maximum deflection of 1/150th of span. The frame will be of 3” x 3” x 1/4” angle iron with all seams welded and ground smooth.
Doors will open past vertical and rest on the frame. The right door panel will have a steel handle made from 3/36's plate steel. The entire assembly will be primed with a shop primer and have one coat of oil based black paint.
Opening Size: 48"x48" (53.25"x53.25" outside)
Opening Size: 48"x60" (53.25"x65.25" outside)
Opening Size: 36"x36" (41.25"x41.25" outside)
Sidewalk doors allow for easy movement of people and products and can be customized with different colors and finishes.
OrderSteelway's lightweight aluminum sidewalk doors feature a locking mechanism for additional security.
OrderGalvanized steel Diamond plate is the solution to hard weather environments or lack of regular maintenance. Different appearance but made to provide service for many years to come.
Order
